DPS-315/350/400/500/630F-T

NOUBELON Digital MIG Pulse series is full digital control with multi-process feature. Due to high end DSP and waveform control technology. It provides outstanding control of arc weld pool and brings spatter free welding quality and high efficient productivity. It can work with digital wire feeder and digital torch to achieve precise control and be ideal for both automatic welding and manual welding.

● 20KHz IGBT Inverter Technology

● Infinite wire feed speed control allows user to adjust the voltage and current accurately.

● 4-drive wire feed system to ensure stable feeding

● Step-less Amp/Volt Adjustment

● Thermal Overload Protected

● 2T/4T(trigger lock off/trigger lock on)

● Easily sourced consumables

● Includes 3m MIG torch, ground clamp, gas regulator

● Pirce : 148,000 – 188,000฿

คำอธิบาย

Multi-process:MMA,MIG/MAG,Pulse,Double pulse MIG.
Easiest possible selection of preset JOBs(welding task) for the different materials, wire diameters, thickness and gas type. Total 100 groups.
Easy use controls to achieve accurate settings and high efficiency. 100 sets of Expert Database for Steel, ER307,ER308, flux-cored, AL99.9,AlSi, AlMg,CuSi and CuAl etc.
Synergic operation–Simply select material and sheet thickness and the stored know-how controls the welding process automatically.
Spatter-free welding—One single droplet filler metal is detached for each current pulse.

Model

DPS-315F-T

DPS-350F-T

DPS-400F-T

DPS-500F-T

DPS-630F-T

Welding current max.

315A

350A

400A

500A

630A

Welding current min.

25A

Welding current/Duty cycle(10min/40℃)

315A@90%

350A@60%

400A@60%

500A@60%

630A@60%

Welding current/Duty cycle(10min/40℃)

310A@100%

260A@100%

320A@100%

360A@100%

480A@100%

Operating voltage

15.5-29.8V

15.5-31.5V

15.5-34V

15.5-39V

15.5-44V

Open-circuit voltage

70V-90V

Mains frequency

50-60Hz

Mains voltage

3x380V/415V/440V

Material support

steel, stainless steel, aluminium, bronze

Operation mode

2T,4T,S2T,S4T,Spot,JOB

Double pulse frequency(Freq)

0.5Hz-5Hz

Double pulse range (Fd2)

0 m/min-2m/min

Degree of protection

IP23

Dimension(LxWxH)

1050x570x1480mm

Weight

120kg(264Ibs)

Specification for Water tank

Input voltage

2*380V

Initial current

0.5A

Water Tank Capacity
